| Rated Output | 20 W (Max 30W) |
|---|---|
| Rated Impedance | 100V line : Hot 500Ω – black, com – white |
| Sound Pressure Level | 96 dB (1W, 1m) |
| Frequency Response | 85 – 20,000 Hz |
| Dispersion Angle | Horizontal : 200° (1kHz); 98° (4kHz) Vertical : 46° (1kHz); 39° (4kHz) |
| Speaker Component | 10cm Cone-type x 4 |
| Connection | Speaker cord (2-core cabtyre cord Ø6mm (0.24″), gray) |
| IP Code | IP44 |
| Finish | Enclosure Case : Extrude Alumunium, black, paint Side Panel : Resin, black, paint Punched Net : Surface tread steel plate, black, paint |
| Dimension | 140 (W) x 560 (H) x 140 (D) mm (5.51″ x 22.05″ x 5.51″) |
| Weight | 3.8 kg (8.37 lb) |
| Accessory | Speaker Bracket …1 Wall Bracket …1 BH Screw M5x60 Fe Blk 3-SEMS …1 |
